Echo 525 Acoustic Liquid Handler Specifications
| Drop volume | 25 nL |
| Volume transfer range | 25 nL – 5 µL one well to one well |
| Transfer accuracy | <10% deviation from target volume |
| Transfer precision | <8% CV |
| Reagents supported | PCR and qPCR reagents, synthetic biology reagents, NGS reagents, primers and probes, cell culture media, proteins, nucleic acids, up to 50% glycerol, serum, plasma, and antibodies |
| Source labware compatibility | EchoQualified 384 Polypropylene, 384 Polypropylene Plus, Reservoir, Microplates |
| Destination labware compatibility | All Echo Qualified Microplates and most ANSI-compliant/SBS-standard microplates in 96-, 384-well formats 8 -16 mm in height. Use of 1536-well plates as destination plates is application dependent |
| Dimensions | 53.9 cm width x 68.3 cm depth x 92.5 cm height (21.2 x 26.9 x 36.4 inches) |
| Weight | 128 kg (283 lbs) |
| Working envelope | Additional 25.4 cm (10 inches) on top, 2.5 cm (1 inch) on sides, 7.6 cm (3 inches) at front, 30.5 cm (12 inches) at back |
| Electrical | AC 120V, 50/60 Hz, 10 A or AC 230V, 50/60Hz, 5 A |
| Operating temperature | 21°C ± 5°C (70°F ± 9°F) |
| Vacuum | House supply minimum 200 Torr (266 mbar, 22 inches Hg Vac) OR Standalone vacuum with surge tank, minimum pump speed 2.0 m3/hr (70.68 cu ft/hr), minimum pressure 100 Torr (133 mbar, 26 inches Hg Vac) |
| Fluid class calibration | No calibration needed |
